• • ENGINE

    Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h

  • DISPLAY

    Yamaha, Side Switch, 1.7" LCD, 7 functions

  • BATTERY

    InTube, 630 Wh

  • FRAME FAMILY

    Winora, Aluminium 6061, Yamaha InTube 630, HD Interface, Aluminium 6061

  • FORK

    SR Suntour, NEX E25, Steel spring, 63 mm travel, Steel steerer tube 1 1/8" - 1 1/2" tapered, Quick release 100mm

  • CRANK ARM

    Winora, forged, Aluminium

  • BRAKE (FRONT)

    Alhonga, HT474, Hydraulic disc brakes

  • BRAKE (REAR)

    Alhonga, HT474, Hydraulic disc brakes

  • TUBE

    Dunlop valve

  • RIM

    Schürmann, Yak25, With Eyelets, Double Wall, Aluminium

  • CLAMPING RING

    quick release, Quick release, 34.9 mm

  • REAR DERAILLEUR

    Shimano, Acera M360

  • SHIFT LEVER

    Shimano, Altus M315, Rapidfire

  • BOTTOM BRACKET

    integrated in the motor

  • SPROCKET

    SunRace, CSM55, 11 - 34 teeth

  • CHAIN

    KMC, e10S

  • CHAINRING

    Steel, 38 teeth

  • BRAKE LEVER

    Alhonga, HT474, Aluminium

  • BRAKE DISC (FRONT)

    Alhonga, DXR1806, 180 mm

  • BRAKE DISC (REAR)

    Alhonga, DXR1606, 160 mm

  • TYRE

    Schwalbe, Al Grounder Performance, 60-584, 27.5 x 2.4 inch

  • FRONT WHEEL HUB

    alu hub

  • REAR WHEEL HUB

    alu hub

  • SPOKES

    Sapim, Leader

  • HANDLEBAR

    Ergoriser, oversize, 720 mm

  • GRIPS

    XLC, Comfort bo3

  • STEM

    aluminium, angle ajustable, A-head, 31.8 mm

  • HEADSET

    Feimin, A-Head Tapered, Aluminium, CartridgeCane Creek, Viscoset, Aluminium

  • SADDLE

    Selle Royal, Essenza

  • SEAT POST

    XLC, Aluminium, Patent, 31.6 mm

  • PEDALS

    VP, E461, Aluminium, with Reflector

  • HEADLIGHT

    Herrmans, H-Black MR-GO

  • REAR LIGHT

    AXA, Juno Ebike

  • DYNAMO

    via system battery

  • CARRIER

    Racktime, RT-336, 25 kg

  • FENDERS

    SKS, Chromoplastics

  • STAND

    Ursus, Mooi, Rear stand

  • LOCK

    Abus, upgradable over Plus System
